OS-EU04F High ratio of performance EPON ONT 1GE+3FE for FTTX Solution with Realtek chipset DC 12V/1A

Basic Information
Place of Origin: China
Brand Name: Opti-S
Certification: CCC/RHOS/ISO9001
Model Number: OS-EU04F
Minimum Order Quantity: 1
Price: Negotiable
Delivery Time: 5-8 work days after payment
Payment Terms: T/T;Paypal
Contact Now
Detail Information
Chipset: Realtek 9602 Power: External Power Adaptor 12V/1A
Pon Rate: Pstream:1.25Gbps Downstream:1.25Gbps

Product Description

EPON ONU ——4FE(1GE+3FE)

    1GE+3FE is devices by Company that Fiber-To-The-House (FTTH) solutions and support ultra-bandwidth access for home or Small Office/Home Office (SOHO) users using EPON technologies.

     It provide POTS RJ11 ports and FE/GE RJ45 port ,WIFI and CATV RF ports, enabling high-performance forwarding capabilities.



Product Specification

Item 1GE+3FE
PON port Rate Upstream:1.25Gbps downstream:1.25Gbps
Optical Output Power -1~+4dBm
Receiving Sensibility -27dBm
Receiving Saturation -3dBm
Port Feature PON 1 port
Data 1*1000Base-T port+3*10/100Base-T ports
Size 180mm(length)*130mm(width)*50mm(height)
Weight ≤0.5kg
Power External Power Adaptor 12V/1A
Power Consumption ≤12W
Operating Environment Operating Temperature 0oC to +40o C
Operating Humidity 10% to 95% (no condensing)






Product Feature:

Item 4FE
PON Feature

IEEE 802.3ah EPON standard

EPON interworking standard of China Telecom and China Unicom

20Km transmission distance on single fiber

128Bits uplink and downlink triple-churning

Standard OAM and Extension OAM management

ONU software batch upgrading

PON port support optical power detection

Ethernet Feature

Support Auto-speed and MDI/MDIX auto detection

Internal L2 switch

Advanced data processing function, such as VLAN label processing, flow classification and packet filtering.

Gateway Feature

WAN support Router and Bridge mode

Router mode supports PPPOE/DHCP/ static IP

WAN support Internet,VoIP,IPTV,TR069

LAN supports DHCP and static IP

Support NAT and NAPT

Support UPnP

OAM Feature

CTC 3.0 standard of China Telecom

TR-069 standard

TR-098,TR-140 terminal integrated management interface standard, service configuration, including Ethernet, VoIP, WLAN

Warning report, performance monitoring

Remote software upgrading through OAM
